Bearing (Embedded) Thermocouples (Type 6)

General Purpose Thermocouples

Send Enquiry Buy Online Request Info Data Sheet

Related Products

Standard Socket

Miniature Socket

A range of fast response miniature embedded (also known as embedment) thermocouple sensors designed for surface temperature measurements in general industrial applications such as in bearing shoe applications to give a reliable indication of bearing wear and oil film breakdown through continuous monitoring of temperatures. These tip sensitive thermocouples have an operating temperature range of -25°C to +250°C and can be supplied with a pressure tested oil seal barrier to prevent leakage. Standard assemblies are easy to install in drilled holes for general temperature sensing applications, whereas the spring loaded ‘top hat’ style assemblies are inserted into a milled hole with a retaining clip, pushed down to compress the spring and retain the sensor against the surface being monitored.

Fast response and cost-effective solution to bearing temperature monitoring
Standard (Cap) or 'Top Hat' style tips
Pressure tested (minimum 5bar/75psi for at least one hour) Oil Seal Barrier (feedthrough) available

Stainless steel and phosphor bronze tip materials
Sensors and Oil seals are rated for use up 250°C
Colour coded to IEC584.3 or ANSI MC96.1

Bearing Thermocouple Enquiry Form

1. Thermocouple Type

2. Tip Style

Illustration	Select
STANDARD (Cap) Style
TOP HAT Style
Duplex Element Required? (please tick box)

3a. Standard (Cap) Style Material

SS - Stainless Steel
PB - Phosphor Bronze

3b. SS Cap Style Sizes (d1 x L1)

3. PB Cap Style Sizes (d1 x L1)

3. Top Hat Dia. (d1) and Material

4. Oil Seal Barrier

Illustration	Select
Not Required
Required

5. Cable Length

5a. Oil Seal Dia.

5b. Oil Seal Length

5c. Cable Length - Tip to Oil Seal

5d. Cable length - Oil Seal to Cold End

6. Optional Thermocouple Plug

7. Colour Code

8. Quantity Required

Qty Required

Contact Details

Company Name

Your Name

Title/Dept.

Email

Telephone

Additional Information

If your enquiry is for more than one style of sensor, please email us with your requirements or use the box below

Send Enquiry

We will only use your email address to contact you. We will never give your email address to 3rd parties and we do not sell data on to any other company. We prefer to concentrate on making quality temperature related products. Our privacy policy can be viewed here.

1	Thermocouple Type	Temperature Range (continuous)	Temperature Range (short term)
K	Nickel Chromium vs Nickel Aluminium	0°C to +1100°C	-180°C to +1350°C
T	Copper vs Constantan	-185°C to +300°C	-250°C to +400°C
J	Iron vs Constantan	+20°C to +700°C	-180°C to +750°C
N	Nicrosil vs Nisil	0°C to +1100°C	-270°C to +1300°C
E	Nickel Chromium vs Constantan	0°C to +800°C	-40°C to +900°C
Temperature ranges refer to the thermocouple type. The temperature range of the sensor may deviate from the above, please refer to the product description for more details
