Miniature Ceramic Thermocouple Socket - Quick Wire - F240

Miniature Thermocouple Connectors rated to 650ºC

Send Enquiry Buy Online Request Info Connector Catalogue

IEC Colours			ANSI Colours
Part No.	Type	Colour	Part No.	Type	Colour
F240K-I	K		F240K-A	K
F240T-I	T		F240T-A	T
F240J-I	J		F240J-A	J
F240N-I	N		F240N-A	N
F240RS-I	R/S		F240RS-A	R/S
F240E-I	E		F240E-A	E
F240B-I	B		F240B-A	B
F240CU	Cu		F240CU	Cu

Ceramic body rated to 650ºC
Available for thermocouple types: K, T, J, N, R/S, E, B and Cu
Thermocouple type indicated by colour coded dot on body
Easy wiring via lipped washer
Accepts stranded or solid wires up to 0.8mm diameter (0.5mm²)

Manufactured in accordance with standard EN 50212
High purity thermocouple alloys used for male pin and female socket constructions
Bevel tipped pins for easy insertion
Polarised flat pins

Related Thermocouple Connectors

Miniature Ceramic
Plug

Part Code: F100 Miniature Ceramic
Plug - Quick Wire

Part Code: F140 Miniature Ceramic
Socket

Part Code: F200

Connector Enquiry Form

F240 Thermocouple Type

Colour Code

Quantity Required

Qty Required

Contact Details

Company Name

Your Name

Title/Dept.

Email

Telephone

Additional Information

If your enquiry is for more than one style of connector, please email us with your requirements or use the box below

Send Enquiry

We will only use your email address to contact you. We will never give your email address to 3rd parties and we do not sell data on to any other company. We prefer to concentrate on making quality temperature related products. Our privacy policy can be viewed here.

Products

Contact Us

About TC

FREE Guide

Privacy Policy

Terms and Conditions

Sitemap

FREE Wallchart Guide to
Thermocouples and RTD Sensors

Join over 500,000 engineers and buyers who have already received our FREE 74 page A3 Guide to Thermocouple and Resistance Thermometry

Company Name		Address 1
Your Name		Address 2
Title / Dept.		County / Region / State
Email		Postcode / ZIP Code
Telephone		Country

Company Name

Your Name

Title / Dept.

Address 1

Address 2

County / Region / State

Postcode / ZIPCode

Country

Telephone

We will only ever use the information you provide to occasionally contact you regarding our products and we will never disclose your details to a third party. Please see our privacy policy for more details.

I agree to the terms and conditions listed in the Privacy Policy

Thermocouple Sensors

Platinum Resistance Thermometers

Cable

Miniature Thermocouple Connectors

Standard Thermocouple Connectors

Instrumentation

Temperature Accessories

Calibration

Pressure

1	Thermocouple Type	Temperature Range (continuous)	Temperature Range (short term)
K	Nickel Chromium vs Nickel Aluminium	0°C to +1100°C	-180°C to +1350°C
T	Copper vs Constantan	-185°C to +300°C	-250°C to +400°C
J	Iron vs Constantan	+20°C to +700°C	-180°C to +750°C
N	Nicrosil vs Nisil	0°C to +1100°C	-270°C to +1300°C
E	Nickel Chromium vs Constantan	0°C to +800°C	-40°C to +900°C
R	Platinum - 13% Rhodium vs Platinum	0°C to +1600°C	-50°C to +1700°C
S	Platinum - 10% Rhodium vs Platinum	0°C to +1550°C	-50°C to +1750°C
B	Platinum - 30% Rhodium vs Platinum 6% Rhodium	+100°C to +1600°C	+100°C to +1820°C
Temperature ranges refer to the operating range of the thermocouple type. The temperature range of the connector will be as stated. Please refer to the product description for more details.
