IEC Colours			ANSI Colours
Part No.	Type	Colour	Part No.	Type	Colour
F30K-I	K		F30K-A	K
F30T-I	T		F30T-A	T
F30J-I	J		F30J-A	J
F30N-I	N		F30N-A	N
F30RS-I	R/S		F30RS-A	R/S
F30E-I	E		F30E-A	E
F30B-I	B		F30B-A	B
F30CU	Cu		F30CU	Cu

Thermoplastic body rated to 220ºC
Available for thermocouple types: K, T, J, N, R/S, E, B and Cu
Body colour coded and thermocouple type indicated on body
Easy wiring via lipped washer
Accepts stranded or solid wires up to 0.8mm diameter (0.5mm²)

Manufactured in accordance with standard EN 50212
High purity thermocouple alloys used for male pin and female socket constructions
Bevel tipped pins for easy insertion
Polarised flat pins

Related Thermocouple Connectors

Miniature
Plug

Part Code: F11 Miniature
Socket

Part Code: F20 Miniature Panel Socket - Rectangle Flanged & Bracket

Part Code: F29 Miniature Panel Socket - Round Flanged

Part Code: F32 Miniature Panel Plug -
Lugged

Part Code: F37
