IEC Colours			ANSI Colours
Part No.	Type	Colour	Part No.	Type	Colour
F31K-I	K		F31K-A	K
F31T-I	T		F31T-A	T
F31J-I	J		F31J-A	J
F31N-I	N		F31N-A	N
F31RS-I	R/S		F31RS-A	R/S
F31E-I	E		F31E-A	E
F31B-I	B		F31B-A	B
F31CU	Cu		F31CU	Cu

Thermoplastic body rated to 220ºC
Available for thermocouple types: K, T, J, N, R/S, E, B and Cu (for RTD's)
Body colour coded and thermocouple type indicated on body
Easy wiring via lipped washer
Accepts stranded or solid wires up to 0.8mm diameter (0.5mm²)

Manufactured in accordance with standard EN 50212
High purity thermocouple alloys used for male pin and female socket constructions
Bevel tipped pins for easy insertion
Polarised flat pins

Related Thermocouple Connectors

Miniature Plug
Three Pin

Part Code: F16 Miniature Socket
Three Pin

Part Code: F25
